Cake Assembling Machine, Straight and Angled

Send an inquiry

Every machine is built to your product size, volume and power supply, then quoted with freight to your port. Tell us what you produce and we will come back with a specification and a price.

V shape, W shape, lean left, lean right and straight. Tube ID 20, 25 and 30 mm.

SKU: BM-CK-14
Category:
Tags:

Description

What it does

Sets loaded tubes into the finished pattern and fuses them together into a block ready for the outer wrap.

Before you order

Pattern and tube size both matter. A fan pattern and a straight pattern are different machines, so list every pattern you produce.

Where it sits in the line

Stage 7 of the Cake Line: Assembly.

Quoted to specification. Machines are built to your product, volume and destination. Send us your requirement and we will quote the machine or the complete line.

Watch the machine running

Specification

Machine Size (L x W x H)
380 x 620 x 220 cm90 x 140 x 135 cm
Gross Weight
900 kg
Shipping Volume
1.70 CBM
Power Supply
380 V 3-phase 50 Hz220 V 2-phase 60 Hz
Purpose
Tube ID 25mm / 30mmtube OD 29mm / 37mm
Mandrel / Matrix
20 x 25 x 15025 x 30 x 17530 x 36 x 225
Rated Output
4000shots / hour

Quoted to specification. Machines are built to your product, volume and destination, then quoted with freight to your port.

The machine running

Filmed at the factory. Output shown is indicative and varies with your product, material and operator.

Where it sits in the line

Cake Line
  1. 1Tube making
  2. 2Clay pressing
  3. 3Chemical preparation
  4. 4Component pressing
  5. 5Fusing
  6. 6Paper preparation
  7. 7Assembly

Also at this stage: Cake Assembling Machine, Fan Shape with Fusing BM-CK-15
